Screw M10×80 – genuine IMER part 2222145

01Where it fits

Where this part sits on your machine

Also on this drawing

All 34 parts on Drawing 4, Gear Box (3226385)
  • 22
    Gearbox oil seal 90×55×10

    3226388

    $12.00In stock

  • 2
    Bearing 6211

    2204569

    $79.00In stock

  • 24
    Screw M10×65

    2222148

    $10.00In stock

  • 9
    Spacer 75×55×10

    3208966

    $20.00In stock

  • 10
    Stop ring E15

    1227330

    $10.00In stock

  • 5
    Gear wheel Z76 M2

    3208970

    $120.00In stock

02Fits

Fits these machines

4 machines · 3 IMER parts books

From IMER parts books 3230425 r07 (2019-02), 3226875 r16 (2018-09), 3228768 r12 (2019-02).

03Where it sits

Ref 21 on the Mortarman 120 Plus drawing

Open full diagram →
Mortarman 120 Plus — Gear Box (3226385), parts list
RefPart no.NamePrice
13209514Gear Box CasingIn stock, $109.00
22204569Bearing 6211In stock, $79.00
33213282Bearing 6208In stock, $45.00
43226384Main ShaftIn stock, $316.00
53208970GearIn stock, $120.00
63208983Bearing 6204In stock, $17.00
73213178Key 10x8x20In stock, $10.00
83209682Bearing 6302In stock, $15.00
93208966Spacer BracketIn stock, $20.00
101227330Stop Ring E15In stock, $10.00
112227207Stop Ring E55In stock, $10.00
123208975PinionIn stock, $63.00
132229250Key 5x5x15In stock, $10.00
143209801GearIn stock, $99.00
153235725PulleyIn stock, $39.00
163226386Gear Box CasingIn stock, $157.00
172227320Stop Ring E20In stock, $10.00
183209799ShaftIn stock, $82.00
192224340Washer 6592 D.10x21 ZincIn stock, $10.00
202223650Nut 5588 M10In stock, $10.00
212222145Bolt 5737 M10x80 ZincIn stock, $10.00
223226388Oil Seal 90x55x10In stock, $12.00
233200094Oil Seal 35x20x7In stock, $10.00
242222148Bolt 5737 M10x65 ZincIn stock, $10.00
253209811GasketIn stock, $16.00
263213180Pin D.8x30In stock, $10.00
272229259Key 6x6x14In stock, $10.00
283226390BushingRequest price
292204505Bearing 6008Request price
301222694Bolt 5737 M10x110 ZincRequest price
312229555Key 10x8x40In stock, $10.00
323226451Pin D.5x16Request price
332223836Nut 5589 M30x2In stock, $13.00
343234539SpacerRequest price

04Specifications

Part details

Part number
2222145(2222-145)
Brand
IMER (genuine OEM)
Condition
New
Size
M10×80, TE 5737 (parts-book note)
Assembly
Gear Box (3226385)
Fits
4 machines

This screw M10x80 is a genuine IMER part, part number 2222145. The IMER Step-Up 120 parts book lists it as ref. 21 in Table 15, Mixing Gear Box (the gear box of the mixer offered as an optional accessory for the Step-Up 120), with the note TE 5737 M10x80.

The same part number is listed as bolt 5737 M10x80 Z in the Mortarman 120 Plus gear box (3226385, ref. 21) and as bolt TE 8.8 5737 M10x80 Z in the Syntesi 300-350 gear box (Table 2/B, ref. 21).

Check the part number against the parts book for your machine before ordering, or contact us with your machine's model and serial number.
