IMER Masonry 750 PlusGenuine IMER
Weight of saw in operation
285kg

01Overview

IMER Masonry 750 Plus at a glance

The IMER Masonry 750 Plus is a saw sold by IMER Parts USA, a certified IMER dealer. Its IMER parts book lists 132 part numbers across 6 exploded drawings. Machines usually ship in 2–3 weeks (from IMER in Italy; the date is confirmed after ordering) by LTL freight, and orders over $1,500 ship free to commercial addresses in the contiguous United States. Ask a parts specialist for availability, options and freight to your site.

  • Certified IMER Dealer
  • Ships from the USA

02Shop parts

Shop Masonry 750 Plus parts by assembly

132 part numbers · 6 drawings

Popular for the Masonry 750 Plus

Ranked by orders, how often the part wears out and availability.

Or pick the assembly. Open a drawing, tap a numbered balloon and add the part to your cart.

03Specifications

Technical data

From the IMER product sheet

Other

Model codes
1188863 - 1188864
Noise level at operator's ear, LpA (running empty)
95 dB
Vibrations transmitted, Aeq
2.33 m/s2

Performance

Max disc diameter
750 mm
Disc hole
25.4 mm
Disc revs (230V/50Hz)
976 rpm
Disc revs (400V/50Hz)
1440 rpm
Disc revs (400V/60Hz)
1475 rpm
Disc revs (220V/60Hz) SPH
1180 rpm
Disc revs (220V/60Hz) TPH
1475 rpm
Disc rotation direction (viewed from the movable disc guard)
clockwise
Max cutting capacity in one pass
300 mm
Max height of piece to be cut
430 mm
Min width of piece to be cut
50 mm
Max cutting length with disc lowered
500 mm
Max cutting length with disc descending from above
560 mm

Motor

Motor (230V/50Hz)
2.2 kW, 220-240 V, 50 Hz, 13.8 A, 1420 rpm, service S1, insulation class F, IP55, capacitor 2 x 50 uF
Motor (400V/50Hz)
5.5 kW, 400 V, 50 Hz, 11.6 A, 1440 rpm, service S3, insulation class F, IP55
Motor (400V/60Hz)
5.5 kW, 400 V, 60 Hz, 11.5 A, 1740 rpm, service S3, insulation class F, IP55
Motor (220V/60Hz) SPH
4.0 kW, 220 V, 60 Hz, 23.2 A, 1740 rpm, service S1, insulation class F, IP55, capacitor 180 uF
Motor (220V/60Hz), 5.5 kW
5.5 kW, 220 V, 60 Hz, 21.6 A, 1730 rpm, service S1, insulation class F, IP55

Dimensions

Cutting table dimensions
490x660 mm
Overall dimensions (width x length x height)
850x1550x1600 mm
Overall dimensions for transport (width x length x height)
850x1550x1600 mm

Weight

Weight of saw in operation
285 kg
Weight for transport
202 kg

04Manuals

Parts book & manuals

Troubleshooting

Masonry 750 Plus not working right?

5 problems from the IMER manual, with the causes, what to do and the parts for each fix.

Open the Masonry 750 Plus troubleshooting guide

Answers

Questions about the Masonry 750 Plus

All answers

05Quote

Request a formal quote

Tell us the quantity, the delivery ZIP and whether the site has a loading dock or forklift. We reply with price, freight and lead time.
