Ref 22 on the Prestige 300 drawing
04Specifications
Part details
This 90° elbow fitting is a genuine IMER part, part number 3224351, listed in the parts books as a 1/2" M-F (M.F.) fitting.
The IMER Small 50 parts book lists it in Table 7, Compressor (1107546 110V/60Hz - 1107547 115V/50Hz), as ref. 30, and in Table 8, Air System, as ref. 4. The IMER Prestige parts book lists it in Table 14, Water Cleaner Pump Kit (ref. 22), and in both Litre Counter Kits, 1107207 (Table 15) and 1107209 (Table 15.1), as ref. 8.
Check that the part number in your machine's parts list matches 3224351 before ordering, or contact us with your machine's model and serial number.
