Laser emitter – genuine IMER part 3228250

01Where it fits

Where this part sits on your machine

Also on this drawing

All 27 parts on Drawing 5, Electric Panel

02Fits

Fits these machines

4 machines · 3 IMER parts books

From IMER parts books Combicut 250 VA, 3227118 r14 (2018-09), 3231790 r07 (2018-09).

03Where it sits

Ref 23 on the Combicut 250 VA drawing

Open full diagram →
Combicut 250 VA — Electric Panel, parts list
RefPart no.NamePrice
13227467Junction BoxIn stock, $81.00
23210114GasketIn stock, $10.00
33210231CoverIn stock, $37.00
43210232CapacitorNot sold onlineAsk a parts specialist
53210233SwitchIn stock, $91.00
63209340Leakage ProtectionNot sold onlineAsk a parts specialist
73225596GasketIn stock, $10.00
83233422Water PumpIn stock, $171.00
93226095Cable Gland Locking Ring PG 16In stock, $10.00
103226101Cable Gland Grommet PG 16In stock, $10.00
113226098Cable Gland Locking Ring PG 11In stock, $10.00
123226100Cable Gland Grommet PG 11In stock, $10.00
133210116Bolt TCTC 4,2x16In stock, $10.00
142222540Bolt TCEI 5931 6x20In stock, $10.00
153210096Bolt TTCQ 5732-65 M8x60In stock, $10.00
162284866Handwheel 180-40-M8In stock, $10.00
173224630Plug with Electric CableIn stock, $78.00
183227508Cable Clamp PG 9In stock, $10.00
193227487Cable Gland Nut PG 9In stock, $10.00
203227481SupportNot sold onlineAsk a parts specialist
213227483Adjustment BlockIn stock, $59.00
223227489Cable Gland Nut M20x1.5In stock, $10.00
233228250LaserIn stock, $49.00
243207155Bolt TC PH 7687 M4x10In stock, $10.00
253227482CoverNot sold onlineAsk a parts specialist
263228251Power SupplyIn stock, $77.00
272222424Bolt TC PH 6954 4.2x9.5In stock, $10.00

04Specifications

Part details

Part number
3228250(3228-250)
Brand
IMER (genuine OEM)
Condition
New
Assembly
Electric Panel
Fits
4 machines

This laser emitter is a genuine IMER part, part number 3228250. The IMER parts books list it as ref. 23, "LASER", in Tav. 5, Electric Panel, of the Combi 250 VA and the Combi 250/1000 VA - 250/1500 VA, and as ref. 26, "LASER EMITTER", in Tav. 6, Disc Guard and Motor Assembly, of the C 350 iPower. Our store has sold it as the laser light.

IMER lists a laser guide to make cuts quickly and accurately as standard equipment on the Combicut 250/1000 and 250/1500.

Check part number 3228250 against your saw's parts list before you order.

05Used with

Often replaced together

Wear parts next to it on the same drawing

06Documents

Parts books

Answers

Questions about the machines it fits

All answers

07Shipping & returns

Shipped from the USA

Shipping & delivery →Returns & warranty →

  • Ships from the USA

    Leaves us in 1–3 business days; ground delivery usually takes 5–7 business days.

  • Free shipping over $1,500

    On orders over $1,500 to commercial addresses in the contiguous US.

  • 30-day returns

    30-day returns on unused items with a return authorization.

08Questions

Good to know

Which IMER saws does laser 3228250 fit?

The Combicut 250 VA, Combicut 250/1000 VA, Combicut 250/1500 VA and Combicut 350 iPower, per the IMER parts book.

Which assembly is laser 3228250 part of?

On the Combicut 250 VA, 250/1000 VA and 250/1500 VA it is listed in the Electric Panel assembly. On the Combicut 350 iPower it is in the Disc Guard and Motor assembly.

Fit check

Not sure it fits?

Send us the model and serial number from the machine’s serial plate, or a photo of it. A parts specialist checks the fit against the IMER parts books before the part ships.
Ask about the fitCall +1 (307) 301-7723
