Ref 19 on the Prestige 300 drawing
04Specifications
Part details
The Cam-Lock Hopper Drain Plug DN65 is a genuine IMER OEM part, part number 3225751. The IMER parts books describe it as a female cam-lock plug, size DN65.
It fits the IMER Step-Up 120, where it is listed in the machine structure and in the street version with mixer, and the IMER Prestige 300, where it is listed in the rear machine structure and in the mixing machine. It serves as the cap for the hopper drain.
