03Where it sits
Ref 39 on the Koine 35 drawing
04Specifications
Part details
This scraper is a genuine IMER part, part number 3223349.
The IMER Koine 4 parts book lists it among the standard supply accessories (TAV.8, ref. 18), together with the scraper rod, part 3223347 (ref. 19). The Koine 35 parts book lists the same part number in TAV.1, Machine Structure, as ref. 39.
Check that the part number in your machine's parts list matches 3223349 before ordering, or contact us with your machine's model and serial number.
05Used with
Often replaced together
Wear parts next to it on the same drawing
