Carriage handwheel M8×45 – genuine IMER part 2284864 for IMER Combicut 350 iPower

01Where it fits

Where this part sits on your machine

Also on this drawing

All 22 parts on Drawing 4, Carriage
  • 2
    RH carriage

    3233137

    $192.00In stock

  • 8
    Nut M8

    2223570

    $10.00In stock

  • 21
    Cap

    3231485

    $19.00In stock

  • 18
    Bearing 608 2RS1

    3204945

    $10.00In stock

  • 4
    Pin D=6×14

    2228820

    $10.00In stock

  • 17
    Pin

    3231484

    $57.00In stock

02Fits

Fits these machines

1 machine · 1 IMER parts book

From IMER parts book 3231790 r07 (2018-09).

03Where it sits

Ref 9 on the Combicut 350 iPower drawing

Open full diagram →
Combicut 350 iPower — Carriage, parts list
RefPart no.NamePrice
13233136LH CarriageIn stock, $266.00
23233137RH CarriageIn stock, $192.00
32222514Screw TCEI 5931 8x40 ZIn stock, $10.00
42228820Pin D.6x14In stock, $10.00
53226230Grub Screw M8x20Request price
63231428Arm PlateIn stock, $10.00
72222061Screw TEFR 5739 8x20 ZIn stock, $10.00
82223570Nut 5588 M8In stock, $10.00
92284864Handwheel M8x45In stock, $10.00
103210629Bearing 6006 2RS1 - CMIn stock, $54.00
113229860Head SpringIn stock, $41.00
123231445Screw TTCQ M10x60 ZIn stock, $10.00
133231422LeverRequest price
142224340Washer 6592 10x20In stock, $10.00
152223920Self-Locking Nut M10In stock, $10.00
162222151Screw TE 5737 M10x70 ZIn stock, $10.00
173231484PinIn stock, $57.00
183204945Bearing 601 2RS1In stock, $10.00
193207397WheelIn stock, $16.00
203207393SpacerIn stock, $10.00
213231485CapIn stock, $19.00
223231981BushingIn stock, $17.00

04Specifications

Part details

Part number
2284864(2284-864)
Brand
IMER (genuine OEM)
Condition
New
Size
M8×45
Assembly
Carriage
Fits
1 machine

This carriage handwheel M8x45, part number 2284864, is a genuine IMER OEM part for the IMER Combicut 350 iPower saw.

The IMER parts book lists it as Handwheel M8x45 in the carriage assembly of the Combicut 350 iPower. Compare the part number with your saw's parts diagram or the handwheel you are replacing before ordering.

05Used with

Often replaced together

Wear parts next to it on the same drawing

06Documents

Parts books

Answers

Questions about the machines it fits

All answers

07Shipping & returns

Shipped from the USA

Shipping & delivery →Returns & warranty →

  • Ships from the USA

    Leaves us in 1–3 business days; ground delivery usually takes 5–7 business days.

  • Free shipping over $1,500

    On orders over $1,500 to commercial addresses in the contiguous US.

  • 30-day returns

    30-day returns on unused items with a return authorization.

08Questions

Good to know

Which IMER machine does part 2284864 fit?

The IMER parts book lists part 2284864 as Handwheel M8x45 in the carriage assembly of the Combicut 350 iPower.

Fit check

Not sure it fits?

Send us the model and serial number from the machine’s serial plate, or a photo of it. A parts specialist checks the fit against the IMER parts books before the part ships.
